Model |
d |
d1 |
D |
L |
L1 |
L2 |
155-10 |
10 |
20 |
18.1 |
20.5 |
5.5 |
15 |
155-11 |
11 |
22 |
20.6 |
23.5 |
5.5 |
18 |
155-12 |
12 |
22 |
20.6 |
23.5 |
5.5 |
18 |
155-13 |
13 |
25 |
23.1 |
28 |
6 |
22 |
155-14 |
14 |
25 |
23.1 |
28 |
6 |
22 |
155-15 |
15 |
29 |
26.9 |
30 |
7 |
23 |
155-16 |
16 |
29 |
26.9 |
30 |
7 |
23 |
155-17 |
17 |
29 |
26.9 |
30 |
7 |
23 |
155-18 |
18 |
33 |
30.9 |
32 |
8 |
24 |
155-19 |
19 |
33 |
30.9 |
33 |
8 |
25 |
155-20 |
20 |
33 |
30.9 |
33 |
8 |
25 |
155-21 |
21 |
38 |
35.4 |
33 |
8 |
25 |
155-22 |
22 |
38 |
35.4 |
33 |
8 |
25 |
155-23 |
23 |
38 |
35.4 |
35 |
8 |
27 |
155-24 |
24 |
38 |
35.4 |
35 |
8 |
27 |
155-25 |
25 |
40 |
38.2 |
35.5 |
8.5 |
27 |
155-28 |
28 |
46 |
43.3 |
39 |
9 |
30 |
155-29 |
29 |
46 |
43.3 |
39 |
9 |
30 |
155-30 |
30 |
46 |
43.3 |
39 |
9 |
30 |
155-32 |
32 |
46 |
43.3 |
39 |
9 |
30 |
155-33 |
33 |
48 |
53.5 |
50.5 |
11.5 |
39 |
155-35 |
35 |
50 |
53.5 |
50.5 |
11.5 |
39 |
155-38 |
38 |
58 |
60.5 |
50.5 |
11.5 |
39 |
115-40 |
40 |
58 |
60.5 |
50.5 |
11.5 |
39 |
|
| Stationary Ring(Carbon/SIC/TC) |
| Rotary Ring(Ceramic/SIC/TC) |
| Secondary Seal(NBR/EPDM/VITON) |
| Spring&Other Parts(S.S/SUS304/SUS316) |
|
